Frank Skerl

VP of Sales at Hamrick Packaging

ROBOX

From Farm to Table: Fully Automated Milk Pasteurization Plant 🥛 We're excited to announce the successful completion of a new, fully automated milk pasteurization plant. This project involved designing and commissioning a state-of-the-art system that maximizes efficiency, hygiene, and product consistency. Key features: ✅ Optimized Process Design: Streamlined pasteurization, heating, cooling, flow control, and CIP operations. ✅ Siemens S7-1200 PLC: Precise control of all plant operations for seamless and reliable performance. ✅ Weintek HMI: User-friendly interface for easy operator interaction and system monitoring. ✅ WinCC 7.0 SCADA Integration: Centralized control, data logging, and trend analysis for optimized plant performance. This project demonstrates Robox's expertise in delivering innovative and efficient automation solutions for the food and beverage industry.

Feb 4, 2025

Theologos Liotakis

Panel is ready... Now it is time for #commissioning #ABBMotion #ACS380 #Weintek #cmt2168X #PLCprogramming #Codesys #PM5052 #AC500eCo #ModbusRTU #encoder #wiring

Mar 28, 2026

Mustafa Attwan, P.E

Two HMIs Somatic and WeinTek connected to one PLC via OPC UA and S7 Protocol. This can be implemented with many UI/HMI throughout the facility.

Mar 19, 2026

Daniel Ribeiro - Automation Engineer

Today was the day to review and make the last software and hardware adjustments in another project that will soon be delivered to the customer. The system was developed with integration between Siemens S7-1500 PLC (CPU 1515-2 PN), Weintek HMI and Danfoss FC 300 frequency inverters, ensuring robustness and reliability in operation. For development and commissioning, the following were used: • TIA Portal V20 (Siemens) • EasyBuilder Pro (Weintek) • MCT10 (Danfoss) Another completed project with a focus on performance, integration and quality.

Mar 21, 2026

DB di Daniele Boldrin

🎥 Revamping - Labeling Machine with Tracking Destacker Design and software development for an automatic labeling machine with synchronised tracking destacking system to the conveyor belt, created in collaboration with LB Service. 💻 Software Development The project included: - Complete management of the machine cycle - HMI supervision development - Parameterization of the motion part - Performance optimization for stability over time - Connection for remote control ⚙️ Hardware - Schneider Electric - Weintek 🔍 Description of the machine The machine is an automatic system designed to: - Destacking by suction cup system with vacuum pump - Position accurately on moving belt - Manage the continuous flow with alarms and stoppages - Download batches of labeled products according to the set set ⚡The electronic control coordinates axes, encoders and labeling devices, ensuring: - High application accuracy - Constant repetitiveness over time - Dynamic synchronization with tape speed - Configurable parameters and recipes based on format and label A solution designed to ensure application quality, production reliability and stable performance even over prolonged work cycles.

Mar 25, 2026

Muhib ur Rehman - Automation Manager, EE

Proud to share my recent project at Riaz Industries Ltd, where I led the commissioning and synchronization of a PV Diesel plant. This complex project involved blending automation and energy management to optimize power generation from solar, generator, and grid sources. Key Achievements: - Installed Weintek HMI to control and synchronize 550kW solar inverters (Inverex 110kW x 5=550KW), 500kW generator, and grid with 149kW net metering load, ensuring seamless transitions. - Integrated energy analyzer for real-time data capture and display on HMI, enabling comprehensive monitoring and load management. - Successfully synchronized power inputs, maximizing efficiency across the PV diesel plant. Gratified to have advanced my programming and technical skills in industrial automation and energy management.

Mar 25, 2026

Hamza H. • Following

🔧 From Semi-Automatic to Fully Automated – Feed Production System Upgrade Proud to share a recent project delivered by our team in an animal feed production facility (poultry, cattle, and goat nutrition lines). The objective was clear: Replace an unstable and faulty control system with a reliable, precise, and fully automated solution. The existing process was running in semi-automatic mode with recurring dosing inaccuracies from multiple silos and limited diagnostic visibility. This was directly impacting efficiency and maintenance response time. Our approach focused on: ▪ Rebuilding the entire control logic on a Siemens S7-1200 PLC ▪ Developing a structured and intuitive interface using a Weintek HMI ▪ Converting the system from semi-automatic to fully automatic operation ▪ Improving dosing precision to near-optimal accuracy ▪ Implementing clear alarm handling and diagnostic feedback for faster troubleshooting The result: ✔ Smoother production cycles ✔ Significantly improved dosing precision ✔ Better operator visibility ✔ Faster maintenance intervention ✔ A more reliable and scalable system Projects like this highlight how structured automation and well-designed control philosophy can transform performance Proud to be part of a team that focuses on reliability, precision, and continuous improvement.

Feb 25, 2026

Innovar Controls - Automação HVAC

Efficient HVAC system management starts with intelligent access to information. With Weintek's WEINCLOUD platform, you can monitor and control your processes in real time, from anywhere and with complete security. Ideal for building and industrial applications, this solution offers intuitive dashboards, integration with PLCs, and data history, ensuring more agility in decision-making and shorter response time for maintenance.

Aug 24, 2025

Mapa Automation & Software

PLC: Schneider Electric TM241CE24T HMI: Weintek MT8017iE TR/ Application: Neutralization of acidic gases in the environment according to ppm values was performed using PID control block. EN/ Application: Using PID control, the system performs neutralization based on the ppm values of acidic gases in the environment.

Jan 20, 2026

Er Sunny

🔹 Smart Automation Upgrade 🔹 Spring Coil Today’s setup was quite interesting… The machine was operated in a combination of Speed Mode and Length Mode. The control architecture included: ➡️ Siemens G120 VFDs (x2) ➡️ S7-1214C DC/DC/DC PLC ➡️ Weintek HMI The main objectives were: 🔸 Maintain stable speed control 🔸 Achieve accurate length measurement 🔸 Provide a simple UI for the operator After running multiple test cycles, the machine performance aligned with the expected results — without additional hard wiring and without disturbing the production logic ⚙️ This is the best part of automation: “Small changes, big improvements.” ✨

Jan 19, 2026

Mapa Automation & Software

PLC: Emerson RSTi-EP CPE100 Standalone Controller HMI: Weintek MT8017iE EN/ Waste Water Treatment Plant Automation System 🔹 PID Controlled Blower Management Depending on the dissolved oxygen (DO) level in the pool, the blowers are operated with frequency control with the PID control algorithm, thus ensuring optimum energy consumption according to the oxygen demand. 🔹 Co-Aging Principal-Spare Motor Working Structure By operating the motors with the principle of co-aging, system continuity is increased, equipment life is balanced and maintenance costs are reduced thanks to the principal-backup structure. 🔹 Intelligent Level Control and Safety Scenarios With control algorithms based on level feedback: Overflow risks are prevented, Engines are prevented from running idle, Process safety and operational stability are increased. The entire system is supported by user-friendly HMI screens that allow the operator to monitor and intervene in the field from a single point. EN/ Wastewater Treatment Plant Automation System 🔹 PID-Controlled Blower Management Blowers are operated with variable frequency control based on the dissolved oxygen (DO) level in the basin using a PID control algorithm. This approach ensures optimal energy consumption by supplying oxygen according to real-time process demand. 🔹 Duty–Standby Motor Operation with Equal Aging Motors are operated based on an equal aging strategy, ensuring balanced operating hours between duty and standby units. This configuration improves system availability, extends equipment lifetime, and reduces maintenance costs. 🔹 Intelligent Level Control and Safety Scenarios Through level-feedback-based control algorithms: Overflow risks are prevented, Dry running of motors is avoided, Overall process safety and operational stability are enhanced. The entire system is supported by user-friendly HMI screens, allowing operators to monitor and control the plant from a single point efficiently.

Jan 23, 2026

Metroid Electrical Engineering

This Form 3bih control panel was manufactured for a new public learn to swim facility located in Brisbane. The new centre features a 20m indoor learn to swim pool and in the board you'll find: Siemens PLC, a Weintek HMI, Danfoss Aqua VSD's and Schneider Electric switchgear throughout. Love working on these commercial pool projects.

Jan 23, 2026

EDDY ALAN RODRIGUES NEVES

Mundial S.A

Mickaël PIERRE

AUTOMATICIEN-ROBOTICIEN at SPIE

Work Done..!! Installation at the end customer. SAT carried out with the customer on the 4 different products...!!. Throughput from 80cps/min to 92cps/min Flowpack double-loading robotic cell with SACARA SR-6iA robot in IrPickTool double Tracking and Cognex external vision. Communication PROFINET. FANUC R-30iB Compact Plus Cabinet. SCHMALZ ejector. Controlling through a WEINTEK display

Dec 12, 2025

Emerson Javier Aldas Lopez

Electronics and Automation Engineer. Master’s Student in Process Management and Automation. Power Generation Maintenance Engineer.

🚀 First phase completed: Full integration of the Intelligent Generation Monitoring Center The first key stage of one of the most challenging and transformative projects I have worked on is officially concluded: the real-time integration of all the generation plants of Empresa Eléctrica Quito towards a unified, scalable and digitally supervised Smart Monitoring Center. This phase included the centralised connection and monitoring of: ⚡ Gualberto Hernández Thermal Power Plant 💧 CH Cumbayá 💧 CH Nayón 💧 CH Paschoa 💧 CH Guangopolo 🔌 (Coming soon) Hidrovictoria Power Plant 🧠 Technical Approach to the Project The system is built on a modern automation architecture that integrates: 🔹 Advanced HMI Weintek cMT-FHDX-820 — Programmed with macros, used for the calculation, treatment, consolidation and optimization of critical variables. — Interfaces designed in EasyBuilder Pro for intuitive, responsive, and operator-oriented visualization. 🔹 Data acquisition from Schneider Quantum PLC — Direct consumption of data on power, flow, levels, MWh, generation curves and mission-critical electrical parameters. — Standardization of protocols and optimization of data structures for reliable WAN performance. 🔹 WAN Communications Infrastructure and Central Broker — Each exchange sends its data in real time to a single node, with optimized telemetry and packet management. — Low latency, redundancy, security and full traceability are ensured. 🔹 WeinCloud Cloud Platform – Executive Dashboards — 24/7 remote monitoring, with just a link to the Weincloud web platform. — Advanced graphs of power, accumulated energy, fuel, efficiencies, transformer states and dynamic behavior. — Daily reports automatically generated in the cloud. 💡 Phase 1 Results ✔️ 100% operational integration of all the plants. ✔️ Real-time visualization of thermal and hydraulic energy production. ✔️ Unified dashboards that allow instant analysis of the energy balance. ✔️ Optimization of supervision for operators, maintenance and management. 🌐 Ultimate Goal Build a platform that takes energy management towards a modern scheme of: Smart Grid, centralized operation, intelligent automation and data-driven decision-making This project marks a before and after in the digitalisation of operational supervision and represents a firm step towards more resilient, efficient and sustainable energy management.

Dec 11, 2025

Hossein Pooladgar

Electrical engineer, PLC Programmer

Upgrade and modernization of the MDF lamination line monitoring system From signal checking to full design of buttons and switches Using Weintek touch panels and Siemens S7-400 PLC With Ethernet communication between HMI panels and the Siemens PLC

Dec 7, 2025

Serhii Obrusnyk

PLC / HMI Programmer

A PROJECT I’M PROUD OF A couple of years ago, I implemented an automation system for a sugar production facility — the chamber press filter station used for suspension filtration. During this project, I created a 3D model of the collector piping and actuator layout, developed the control algorithm from scratch on a VIPA 300s PLC, and fully built the interfaces for a Weintek HMI panel and a WinCC Professional SCADA system. This was my first PLC, SCADA, and HMI project that I completed entirely on my own. The most rewarding part was seeing the 3D model come to life and watching the mechanisms operate exactly as I had defined in the logic.

Dec 6, 2025

truxie

For these projects, I've selected Weintek HMIs - I'm working in EasyBuilder Pro, and it seems like it'll be more than capable for my needs. Someone in this sub suggested them, and I'm liking the software more than the one for the CMore HMIs (and some other brand I've forgotten at the moment). So that part is set. 2 projects - OEM machine that controls some smaller pumps via relays and digital inputs, and monitors tank volume via a 4-20mA pressure sensor. In-house manufacturing line that will pump chemicals and use IO-Link flowmeters from IFM and likely some 4-20mA level sensors, and trigger some output relays.

Nov 2, 2025

muramasa-z

Our production line wants to create an awareness dashboard with modern web technology. We want to extract data logs via Weintek, as our current system uses Siemens PLCs and HMI. The old vendor used Siemens environment tools like WinCC and TIA Portal to create a dashboard, but we can't afford to purchase a license. So we've decided to extend our topology using Weintek instead.

Nov 25, 2025

Adam Thraves MIET

Controls Engineer

New panel for a chilled water system using the Weintek CMT3218XP 21.5" HMI - Great looking piece of kit. Looking forward to getting this one installed on site 😀 Graphics to follow when commissioning is underway! We'll be using this as part of an IO link system to display temperature, pressure and flow rate for 14 machines. For systems like this I always opt for IO link as it provides us quick and easy expansion to the system. The systems we design are very versatile and can be used in a range of applications, using only the best equipment we can provide solutions for any industry.

Nov 28, 2025

engineerj

I've used them quite a bit as Maple systems screens. I like that they can talk to a ton of different PLC types. I mainly use it for Allen-bradley cause the weintek is a lot cheaper than the panelviews. Heck, there was one project on a dredge in Savannah that used a 4" weintek just to switch screens on a factorytalk SE Application.

Nov 13, 2019

George

Automation Engineer

A few moments from a project I’m really proud of: A capsule packaging machine using a Siemens PLC, Festo servo systems, Uteco sensors, a Weintek HMI, and additional automation components from Schneider Electric. It’s always a great feeling to see the automation run smoothly after many hours of programming, testing, and fine-tuning!

Nov 14, 2025

Dominggos

Automation Engineer

Controlling the Nidec NE300 Inverter using a Weintek HMI. Learning the various communications is tiring 😵‍💫 , but fun 🔥

Nov 14, 2025

Mickaël Pierre

Automation Specialist

Work Done..!! FAT carried out with the customer on the 4 different products...!! Getting started and SAT in 15 days. Customer satisfied and reassured on a cadence of 92 cps/min for 90cps/min in the specifications. Flowpack double-loading robotic cell with SCARA SR-6iA robot using IrPickTool double Tracking and Cognex external vision. Communication PROFINET. R-30iB Compact Plus bay. Controlling through a WEINTEK display

Nov 13, 2025

Kazem Sharifi Nik

Control Systems Engineer

10 Bar Smoke Tube Dual Fuel Boiler Panel Retrofit Hardware: Controller: SIEMENS S7-1214C AC/DC/Rly Monitoring: Weintek HMI MT8102iP Software: TIA Portal V18

Nov 8, 2025

Hydroautomatyka

This time, our team has developed a system for controlling the AUX systems of the FTIR detector – from design, through execution, to commissioning. Inside: Fatek PLC, Weintek HMI panel, Siemens, Eaton and Phoenix Contact components – all in a robust RACK housing. The whole thing is powered by our proprietary software, which ensures reliability and ease of use. We are happy with every such stage – when technology, experience and passion together create an efficiently functioning solution 💪

Nov 5, 2025

Neil

Engineering Manager

Two identical control panels ready for shipping to a customer I like the weintek hot spot facility on the faceless HMI it's a good way for putting a screen in awkward places also accessing plc anywhere around the machine.

Nov 8, 2025

Muhamad Rizqi Firdaus

Electrical Engineer | System Integrator | Automation System

In early October, I conducted a test of the Fire & Alarm Monitoring system for LVMDB panels at PT Hitachi Astemo, Plant 2 Karawang. The system is designed to detect increased temperature and smoke presence in stages with different automatic responses at each level: Level 1: The system provides early warning in the form of a tower lamp on top of the LVMDB panel as well as a yellow warning light in the security area and panel room. Level 2: The system lights up a red light and buzzer in the panel room as a sign of critical conditions. Level 3: The system automatically activates the extinguishing valve to deal with potential fires. In addition, if the smoke sensor detects smoke, the system will also immediately open the extinguishing valve and turn on all warnings at the same time. This test is part of the integration of Schneider PLC-based systems and Schneider and Weintek's HMIs, which aims to improve the safety and reliability of electrical installations through responsive monitoring and automated actions.

Oct 31, 2025

Abdul Rafay

Industrial Automation Engineer skilled in PLC programming, HMI design & PV–Diesel hybrid systems.

Successfully commissioned a 500 kW Solar PV – 100 kW Diesel – Grid Hybrid Power System The system is controlled using Siemens S7-1200 PLC and Weintek MT8072iP HMI, ensuring seamless power management and automation. Proud to contribute toward a smarter and sustainable energy future 🌞⚙️

Oct 28, 2025

Dawood Ali

Electrical Engineer | Controls & QA | Power & Automation | Renewable Expert

✅ Project Commissioned & Integrated Successfully ! 🌞⚡ We are proud to announce the successful testing and commissioning of a 2000.780 kW DC Solar Power Plant at Treet Battery Limited Faislabad another milestone in our journey toward sustainable industrial energy solutions. 🔹 Project Highlights: • DC Capacity: 2000.780 kW • PV Modules: 2,818 Nos. of Tongwei Solar 710 Wp (Ranked #5 globally) • Inverters: 6 Nos. Sungrow SG350 HX (350 kW each) • Communication: Sungrow Smart Logger 4000 • Hybrid Configuration: PV Diesel/Grid Synchronization • Diesel Gensets: 3 x 2250 kVA synchronized via Weintek PV-Genset Controller The system is designed to operate seamlessly in parallel with 1, 2, or 3 diesel generators, ensuring stable power supply, maximum solar utilization, and optimized fuel savings, a true example of smart hybrid integration.

Nov 4, 2025

Al Amin Mia

Electrical Engineer (Automation)-Hyundai Movex Co

⚙️ Powering Precision Lifting – Mitsubishi FR-A800 Inverter in Hoist Automation In automation, motion control isn’t just about speed — it’s about stability, safety, and precision. Recently, I’ve been working hands-on with the Mitsubishi Electric FR-A800 Series Inverter (VFD), used to control hoist motors in the Cargo Terminal Conveyor Management System HSIA - ICT Site. This inverter delivers exceptional torque performance, smooth speed variation, and advanced safety features — essential for hoist operations where every lift and drop must be accurate and controlled. By integrating it with Mitsubishi R16 PLC and Weintek HMI, I explored: 🔹 Advanced speed and torque control for hoist mechanisms 🔹 Smooth start-stop profiles for load safety 🔹 Auto/manual mode switching via PLC logic 🔹 Real-time monitoring through HMI and SCADA Working on this setup reminded me how precision and reliability define automation. Every well-tuned inverter parameter transforms a heavy mechanical system into a smart, efficient, and safe operation.

Oct 30, 2025

Vib Otomasyon

In 2023, we commissioned a 12-Stand Continuous Rolling Line with the following specifications: • Commissioned using Allen-Bradley CompactLogix PLC and FactoryTalk View SCADA. • Ethernet IP communication Siemens AC Drives for Relay Lines, Cassette, Comb, Chains, Aramakas, and Profibus communication Sprint DC Drives for Rolling Stands and Reel. • Monitoring and control provided with FactoryTalk View SCADA and Weintek HMI. • Ethernet switches for short-distance RIO and drive communications, and fiber optic switches for distances of 50 meters and above. • A Recipe application was prepared using VisualBasic Script via SCADA for storing parameters related to pulled products. • A Reporting system was prepared using SQL-supported Weintek HMI and MSSQL for remote access and statistics.

Oct 30, 2025

Muhammad Noor Hakim

Automation Engineer at Wimatic Hexindo

💧 COD Water Monitoring — Integrating Weintek HMI & Schneider PLC In wastewater treatment systems, the Chemical Oxygen Demand (COD) value is a crucial parameter that must be reported to the Ministry of Environment (KLHK) to ensure that wastewater is properly managed and does not harm the environment. Recently, I completed a COD Water Monitoring project where the COD values are displayed in real-time on a Weintek HMI and automatically control valves through a Schneider PLC. I developed both the PLC program and the HMI interface myself, using Modbus TCP for seamless two-way communication between the devices. To prevent corrosion in humid environments, I used a polycarbonate panel enclosure. This material provides better resistance to moisture and mild chemicals, making it an ideal choice for automation systems in water treatment areas. 💡 Lesson learned: Through this project, I realized that simplicity in HMI design plays a vital role — a clear and informative interface allows operators to quickly understand the system condition and operate it efficiently without confusion. Industrial automation is not only about efficiency but also a commitment to protecting our environment 🌍.

Nov 1, 2025

Darby Kramer, CFPS, CMRP

President and Co-Founder of Dynamic Motion Industries LLC

Main panel build is WIP at the Dynamic Motion Industries LLC shop. This will be part of a two panel system being delivered to a customer site in late November with on site installation and start support by our team in Illinois. This system will monitor the safe system status and control four immersion heaters at an aluminum die casting plant.

Oct 23, 2025

Mickaël Pierre

Automation and Robotics Engineer at SPIE

Work in progress..!! Dual-loading robotic cell for a Flowpack machine using a FANUC SR-6iA robot in IrPickTool dual-tracking mode with external Cognex vision. PROFINET communication. R-30iB Compact Plus control cabinet. Operated by a Weintek touchscreen.

Oct 22, 2025

Hydroautomatyka Sp. z o.o.

Project after project – we grow together with our customers! 🔩 This time we supply a complete control system for a hydraulic power unit with a 75 kW motor. Scope of implementation: ➡️ Control cabinet – designed and manufactured by our team ➡️ Components: m.in. Rittal, Eaton, Phoenix Contact ➡️ Control based on Fatek PLC and Weintek HMI panel ➡️ Proprietary software for PLC+HMI ➡️ Installation, commissioning and functional tests at the customer's premises

Oct 22, 2025

Seyyed Amirhossein Saadat

Control Systems & Power Electronics Researcher | Nonlinear Control, Optimization & Neural Networks | Automation & Intelligent Systems Developer

One of my favorite HMI design projects was the graphical interface for a palletizer machine. Although I didn’t have enough time to refine every detail as I wanted, it still remains one of my favorite designs — a balance between simplicity, usability, and visual appeal. It was also a great experience working with Weintek HMIs, and despite the tight schedule, I truly enjoyed the design and testing process. I’m also really glad to have collaborated with Tayebe khani , the project supervisor — her guidance and support played a big role in moving the project forward. For me, HMI design isn’t just about arranging buttons; it’s about creating an experience that feels right for the operator.

Oct 17, 2025

Al Amin Mia

Electrical Engineer-Hyundai Movex Co. LTD.

🖥️ Exploring Smart Control with Weintek HMI (MT8121XE) In modern industrial automation, HMI (Human Machine Interface) plays a vital role in bridging operators and PLC systems. Recently, I’ve been working with the Weintek MT8121XE HMI — a 12.1” high-performance touch panel that offers fast response, clear visualization, and smooth integration with Mitsubishi PLC (R16 series) using EasyBuilder Pro software. This HMI provides: 🔹 Real-time monitoring of conveyor operations 🔹 Alarm management and event tracking 🔹 Data logging and trend visualization 🔹 User-friendly interface for manual and auto control Currently applying this system in Cargo Terminal Conveyor Management at Export Cargo Terminal (Hazrat Shahjalal International Airport). where visualization and reliability are key to continuous operations. Automation isn’t only about programming — it’s about making control smarter, simpler, and more connected.

Oct 20, 2025

IoEDTec Systems

Low cost supervisory system without limits of internal access TAGs, remote access, alarm notification, SQL database support, online DASHBOARD and others.... built with CMT FHDX 820

Oct 2, 2025

Chris Elston

Chief Robotics Manager | MrPLC.com Founder | Automation Geek | FRC Coach 1501

I am impressed with the headless HMI with HDMI output. Two hours out of box and connected to 7 PLCs! I mean it’s been awhile since I used Maple Systems. I liked their stuff in my previous life but the headless HMI with HDMI is something to talk about. You can connect up to 64 PLCs to a single unit with an impressive list of over 300+ drivers as usual. I like to give kudos to people and companies who make Controls Engineer’s lives easy. Unboxing to 2 hours talking to 7 PLCs and displaying data on a TV? Impressively easy! Downside? Rumor mill from other plants and customers I have talked to about this setup is a TV is designed to be installed in our living room so the industrial environment gives a TV about a 1 year life span is the feedback I received from others…not really designed to be hung in a hot warehouse showing off your OEE scores…but the TV cost $300 and the cMT-FHDX-820 is $765…. Not bad. Did I mention that from power “ON” to updating tags is a mind blowing 9 seconds?

Aug 7, 2025

JD Controls LLC

Having a little fun giving this controls library a makeover. At first I typically just focus on functionality, without making things too ugly, but understanding they will need some love in the future. The popups are due for some love. This is continuation of my "PlantPAx Lite" (I do need a better name for it) controls library using CODESYS North America and Weintek Easy Builder Pro HMI software. I'm developing a library very similar in look, feel, and functionality to PlantPAx, but much lighter - just covering the basics and easily scalable if the customer needs. OEMs, skid/machine builders, manufacturers - this is a very cost effective solution to your automation needs. No software contracts, more affordable hardware, and this solution is built to be programmed and deployed quickly.

Oct 14, 2025

Furkan Yuce

Electrical Automation Engineer / PLC Programmer

Weintek fhdx820 LS electiric plc with exhaustion project

Oct 9, 2025

Mehmet Işık

IT Specialist & Software Developer

I am working on #HMI programming with #Weintek for the passenger boarding bridges produced by the company I work for, UBS Airport Systems. These HMI systems are installed in airports across many cities and countries, where they are used in the operator cabins to control passenger boarding bridges safely and efficiently. Through this project, I have gained valuable experience in industrial automation, control systems, and aviation technologies, while also contributing to solutions that are deployed on a global scale.

Sep 20, 2025

Matheus Carvalho

Tecnólogo em Automação Industrial

🔥 Automation / Maintenance / Projects / Engineering 🔥 📃 Presenting another successful retrofit, where we replaced the PLC (discontinued) and an old HMI, with an updated system (Rockwell Micrologix 850 + Weintek 7" HMI) with the update of the Programming Logic. ⛔ The customer had reported to us a great concern with the operation of the machine, which was already being operated manually by the team, because in another occurrence it was not possible to make it return to automatic operation due to some failures in the system. 🖋️ As it is an old machine, no history of projects and descriptions of operation were found. Therefore, a reverse engineering work was carried out for detailing and elaboration of a process and control description. Sizing of control hardware and other components. Involving the following steps: ✅ Monitoring and surveys in the field together with the operation team; ✅Preparation of Process Descriptive and control; ✅Preparation of the Electrical Project; ✅Control Hardware and HMI Specifications; ✅Specification of the components of the Panel; ✅Disassembly of the old Hardware, and assembly of the new Hardware; ✅TAF of the Control Panel; ✅Development of Programming Logic; ✅HMI configuration; ✅TAF of Logic; ✅Installation of the Panel in the field; ✅Machine commissioning; ✅Intervention and support in the resolution of instrumentation problems; ✅Startup; ✅Assisted Departure; ✅Operational Training; ⚠️ Don't wait for your machine or process to stop due to lack of maintenance or replacement of discontinued components and systems. Make a plan to update your automation system. 🟢 OAK Intelligence in Automation Projects.

Sep 19, 2025

Usman Mushtaq

Industry 4.0 Solutions Architect

We successfully automated a Flexo Printing Machine by synchronizing its rollers and integrating all I/O signals. Both analog signals (such as speed) and sensor-based counting were connected and displayed on the HMI. The project was implemented using a Mitsubishi PLC and a Weintek HMI, ensuring smooth operation and real-time monitoring.

Sep 22, 2025

Fathan Qaedi

Automation Engineer | Instrumentation Engineer

I’m grateful to have been part of the development process of Bank Indonesia’s data center. I had the opportunity to work as a system programmer on the chiller leakage line, where I integrated 253 leakage sensors from ICPDAS using the Modbus RTU protocol and programmed them with Weintek HMI as the alert and logging system. This was a significant opportunity for me to contribute as an engineer involved in the project.

Sep 23, 2025

La Serena snc

ELECTRICAL PANEL FOR DOSER WITH LOAD CELL WITH INTEGRATED PLC KEY FEATURES: 1. Dosing accuracy: User-friendly interface with HMI display that allows inverter adjustment 2. Advanced management: via Siemens S7-1200 PLC with Weintek HMI interface 3. Remote monitoring and control: Full visualization and control via IXON cloud platform 4. Integrated data log: Save on USB or automatically send via email the dispensing made OPERATION: In all operating modes, dosing data can be recorded on a USB stick, allowing for comprehensive monitoring and detailed analysis of operations. In addition, the pump speed can be easily adjusted via a selector switch on the HMI. 1. Automatic Mode (Control via HMI): The discharge takes place as long as the operator keeps the control pressed. Once unloading is complete, the system automatically performs the loading phase, preparing the cylinder for the next cycle without the need for further intervention. 2. Automatic Mode (PLC control of the system): In this mode, the feeder works in integration with the PLC of the system in which it is mounted. The settings entered in the HMI are no longer considered, and dosing will take place as long as the dry contacts, connected to the PLC, remain closed. At the end of the unloading process, the cylinder automatically fills up after 5 seconds, ensuring continuity of operation. 3. Manual Mode (Deadman Operation): The dispenser can be used in manual mode for applications where an operator is required. In this mode, the loading and unloading of additives is manually activated by pressing the dedicated button on the HMI panel. 4. Additional Functions: - Inverter parameters: frequency adjustment and slowdown to avoid overdosing - Delayed start: Start delay setting - Data log: record and download data to USB and send via e-mail to configurable groups of recipients - Alarm management: viewing, downloading to USB or sending via email the detected alarms - IXON Cloud remote connection: browser access with dedicated credentials for direct control or view-only SPECIFICATIONS: - Power supply: 220V AC - Analog output: 4 – 20 mA - IP 55 electrical control panel in painted sheet metal (RAL 7032) dimensions 500x400x200 according to CEI 17/13-1 standards - HMI panel in painted sheet metal (RAL 7032) dimensions 300x200x80 according to CEI 17/13-1 standards - USB, Ethernet connections - WEINTEK 7" DISPLAY

Sep 23, 2025

Richard Arancibia

Ingeniero civil mecatrónico

Turning automation challenges into seamless integration – in just 30 minutes. ⚙️🚀 Ever faced an automation system that just isn’t delivering? Watch this quick demo where I take a PLC from another automation provider—struggling with performance issues—and transform it into a fully functional, high-performance system in just 30 minutes. What I integrated into the Weintek HMI: ✅ Manual/Auto mode ✅ Fault history tracking ✅ Emergency stop localization ✅ Speed adjustments ✅ Box counting ✅ Performance Dashboards No overcomplication. No delays. Just smart, efficient solutions that deliver immediate value.

Sep 27, 2025

Amedeo Fratangeli

Software Developer

Presentation of a project that covers the entire technology stack, from the physical sensor to the analytics dashboard. The goal is to transform raw data into a powerful tool for comparing and optimizing production processes. Solution architecture: 1️⃣ Robust Data Acquisition (PLC): A PLC cyclically samples over 100 process variables. To handle lossless communication to the database, FIFO logic has been implemented that buffers samples. 2️⃣ Secure Communication (HMI): A Weintek HMI acts as a gateway and communicates with the PLC through a "handshake" mechanism: the HMI writes data to the MySQL database, waits for confirmation of writing, and only then does the PLC send the next data. This ensures zero data loss. 3️⃣ Backend (PHP/MySQL): A PHP script connects to the database to extract the required data efficiently. 4️⃣ Frontend and Data Visualization (JavaScript/Chart.js): The heart of the project is a web dashboard developed for: - Select up to 3 datasets from completely different time periods. - Overlay the graphs to visually compare the progress of the processes. - Calculate key statistics (maximum, minimum, mean, and standard deviation) in real-time to measure process stability. - Set visual alarm thresholds to immediately identify anomalies. This tool transforms historical data into immediate insights, allowing you to answer questions such as: "Was yesterday's processing more stable than last week's?"

Sep 27, 2025

Metroid Electrical Engineering

Control panel for the equipment upgrade of an existing waterplay area at a riverside park in regional QLD. IT features Schneider Electric switchgear and a Weintek HMI. The board provided control and water treatment to 3 key areas: - The "Water Stream" region, where water is pumped into a boat feature and trickling down through a concrete stream. - "Splashpad" region, where water is pumped into a series of jumping and cascade jets, draining to a perimeter strip drain. - "Wreck Pool" region, where water is pumped into a shallow pool through eyeballs in one wall, draining through to an overflow grate. All water then drains to a balance tank where it is then treated and returned to the other end of the tank.

Sep 28, 2025

Ahmad Farobi Abdurrohim

Fresh Graduate of Power Plant Engineering Technology Applied Major | Internship at PT. Paiton Operation & Maintenance Indonesia (POMI) | Renewable Energy, Electrical, Gas, Oil and Mining Enthusiast

Water Cooled Chiller System by PLC (Programmable Logic Controller) Omron and operated via HMI (Human-Machine Interface) Weintek The objective of this project is the design and implementation of a SCADA (Supervisory Control and Data Acquisition) system for a Water-Cooled Chiller System through the integration of industrial-grade hardware and software. The system models the air cooling process via water circulation, managed by an Omron PLC and operated through a Weintek HMI. Real-time monitoring is facilitated by an OPC UA server and client framework, with supporting software including CX-Programmer, KEPServerEX, and EasyBuilder. The developed system has been successfully realized with features of automated control, real-time monitoring, and dependable fault management. The seamless integration of PLC, HMI, and OPC UA illustrates the efficiency of SCADA technology in industrial cooling applications. The project underscores the critical role of integrated system design in enhancing energy performance and ensuring operational reliability.

Sep 30, 2025

Faisal Ali

Automation Department

Successfully completed the Weintek CMT Series HMI project at Sapphire Diamond & Finishing The project involved complete HMI design, communication setup, and system integration — ensuring smooth monitoring and control of industrial operations.

Oct 6, 2025

Andy Eka

Automation Machine Manufactures

Cup Filling Sealing 16 line Production speed up to 21,000 cups/hour with a power of 16 kW.

Sep 18, 2025

Enes Taşdemir

Panel Testing & Commissioning Specialist ⚙️ | Master Touch in LV Systems

🔹 Data Center | Generator Synchronization & Transfer Control Panels 🔹 Not just a panel project… The heart of critical infrastructure. 📌 What did we do? • Designed 2 Master Panels (MAS 1 & MAS 2) to ensure the continuity of the data center’s power supply. • Independent generator groups are controlled through these panels, providing full redundancy. • Every detail executed with uncompromising quality: • PLC: Siemens • Control: DEIF • Circuit Breakers: ABB & Schneider • Relays: Schneider & Phoenix Contact • Terminal Blocks: WAGO • Push Buttons: Schneider • HMI Panel: Weintek • As İksel Elektromekanik team, we completed the manufacturing, assembly, labeling, and wiring with long hours of dedicated work. 📌 Result: A fully functional, dual master panel system with complete synchronization and transfer capability, delivering high reliability. ⚡ The MAS panels you see here are not just control panels; they are the outcome of team spirit + quality engineering + world-class components combined.

Oct 3, 2025

Pentagon Industrial Automation

Synchronisation,Registration, Inspection,and digitalization in converting

Retrofitting Project Pelican Solventless Lamination machine We congratulate to our Team. Machine Details Machine make - Pelican India Machine speed- 350MPM VFD used in Automation- Siemens CPU - Siemens Hmi - weintek

Oct 1, 2025

Adam Thraves MIET

Controls Engineer

📸 Another recent project controlled using Siemens S71200 and simple HMI application made using Weintek IP series.

Aug 5, 2025

Guillermo Abrain

Gerente y Programador en ADISA-PROYECTOS.

Finishing the simulation phase with a Treatment Plant client, this time with no major difficulty, but the client required a greater number of operating options so it has been quite complex. ✔️ Siemens S7-1510 PLC. ✔️ Weintek HMI. ✔️ IXON router. ✔️ Remote Access. After this phase, the FAT and SAT tests await us, and finally the commissioning.

Aug 6, 2025

Raed Gamal

A Water & Waste Water Treatment | RO Desalination | Automation Control Engineer| PLC& HMI & SCADA

I installed it in the sewage water treatment plant Because the Weintek HMIs offer several advantages, including a wide range of models and protocols, robust connectivity, user-friendly software, and advanced features like remote access and cloud connectivity.

Aug 1, 2025

Enes Taşdemir

Panel Testing & Commissioning Specialist ⚙️

⚡ Synchronization panel FAT result: ZERO errors! I personally carried out all wiring, labeling, control connections and pre-testing of a 5-generator synchronization panel. 🔍 The outcome: Every single check by the client's engineers passed with flawless approval. 👷 ♂️ Coming from the workshop floor, I don't just "build panels." I deliver each project as a signature of craftsmanship and expertise. 💡 Symmetry in cable ducts, precision in connections, accuracy in testing... These are not coincidences, but the result of respect for my profession. 🔧 Technology + Craftsmanship: • DEIF – Synchronization & control • Schneider Electric – Switchgear equipment • Phoenix Contact – Terminals & accessories • Enko – Rectifier • EAE – Panel body • Siemens – PLC • Weintek – HMI screen 🏆 For me, success isn't about "it works." Success is delivering projects that are flawless, reliable and impressive. 😉 In short: Quality hides in the details, and I delivered it with zero errors.

Sep 2, 2025

Deka Perlanda

Assistant Manager Engineering - Electrical & Automation at Mewah Group

"As long as you are still breathing, forever you still have to keep learning💪🏻" The next automation project, thank God for success✊🏻 Big Thanks to ADS team-Muaro Jambi🤝 #Siemens #Weintek #Automation #Engineering

Aug 26, 2025

Emerson Javier Aldas Lopez

Electronics and Automation Engineer. Master’s Student in Process Management and Automation. Power Generation Maintenance Engineer.

🚀 Smart Monitoring Center: Connecting Generation in Real Time Key advance in the project: Intelligent Monitoring Center, designed to integrate and supervise in real time the Cumbayá, Nayón, Pasochoa, Guangopolo, Gualberto Hernández Thermal Power Plant (broker) and soon the Hidrovictoria Power Plant. The system is based on advanced Weintek model cMT-FHDX-820 HMI devices, programmed with macros in C language for the calculation and processing of production and consumption data. In addition, the graphical interface was developed in Easy Builder Pro and the information was taken from a Quantum Shcneider PLC in each plant. Each central is connected through a WAN network, sending its critical variables to a central node, and all the information is stored and visualized on the WeinCloud web platform, through executive dashboards. 🔹 Key Benefits: ✅ Real-time monitoring of critical electrical and mechanical parameters. ✅ Centralized and remote management of operational information. ✅ Greater resilience and continuity of the electricity system. ✅ Optimized daily and monthly reports in the cloud. ✅ Preparation for a scalable, digital and sustainable model. The integration of state-of-the-art hardware, specialized programming, and cloud platforms paves the way for more efficient, secure, and reliable energy management. 🌍⚡

Aug 25, 2025

Mohamed Mansy

Mechatronics Engineer | Mechanical Design | Automation and Control

🔹 Engineering the Nitrogen Skid Unit – Power Meets Intelligence One of the most exciting projects I’ve worked on at HydroSERV was the Skid Nitrogen Pumping Unit – a system that combines mechanical power, safety, and smart automation in one compact design. These units are capable of delivering nitrogen at pressures up to 10,000 PSI and flow rates up to 180,000 SCFH, and they are essential in: ✅ Well servicing & intervention ✅ Pipeline & valve pressure testing ✅ Purging & blanketing to prevent oxygen/moisture ✅ Drying operations for tanks & pipelines ✅ Inerting in refineries & chemical plants ⚙️ Key Components of the Unit: High-Pressure Pump – delivers nitrogen reliably at extreme pressures. Vaporizer System – converts liquid nitrogen into usable gas. Detroit Diesel Engine – the driving power of the unit. Storage & Piping System – safe distribution and flow handling. Skid Frame – a compact, mobile structure I designed in SolidWorks to house and protect all equipment. 🔧 My Contribution – Where Mechatronics Comes Alive: Mechanical Design: Created the Skid Frame and drafted precision components like the IN-2 Plunger Clamp, ensuring manufacturability and accuracy. Automation & Control: Installed and wired pressure, flow, and temperature sensors directly to the PLC. Built a jack (junction) box to organize and simplify the control circuit. Integrated a DC–DC power converter, terminal blocks, fuses, and relays for safe and stable operation. Connected the Detroit Diesel engine control panel with the automation system. Programmed a Weintek HMI, giving operators an easy interface for: Live monitoring of pressure, flow, and temperature Alarms and safety interlocks Calibration and data logging

Sep 13, 2025

Furkan Yuce

Electrical Automation Engineer / PLC Programmer

aluminum extrusion press, puller, furnace installation, software and commissioning...

Sep 12, 2025

Hunter Harris

Behind every great beer, wine, or spirit is great equipment & software.

Vessel: 400 L still with distillation column. Heating System: 5 × electric heaters with automated control. Temperature Control: Precision temperature monitoring and regulation of product. Flow Measurement: Integrated flow sensor for process monitoring. Volume Measurement: Continuous measurement of total vessel volume. Mixing System: Motorized mixer for homogeneous product processing. Control System: Siemens S7-1200 PLC for process automation. Operator Interface: Weintek HMI for control, monitoring, and visualization.

Sep 10, 2025

Mohamed Zedan

Head engineer of electric department for RES

Thrilled to share software retrofit & complete upgrade for Reverse Osmosis (RO) plant located in oil field in the Red Sea. The system had a third-party (Turkish) software, caused operational challenges in critical processes such as CIP (Cleaning in Place) and Production. The retrofit provided optimization of different processes and full control of the equupment. ✅ System Highlights: • PLC: Siemens S7-1200 • HMI: Weintek

Aug 26, 2025

Simon Allen

Control Systems Engineer

Nice week on site. Removal of an old failed control system. New system installed and commissioned successfully. Another happy customer. Tricky bit fitting everything in the same size footprint. Easy 👌 HMI and PLC programmed to keep control and upfront control similar to original for a smooth transition and ease of use for the operators.

Aug 29, 2025

Jānis Griķis

An engineer doesn’t think in problems, he thinks in possibilities!

Recently I had the opportunity to work on a project at Vides Acmhainní Centrs. The task was to ensure real-time visibility of shredder operation and achieve greater energy efficiency and productivity. With the new HMI panel, operators can now: ▪️see shredder performance in different modes, ▪️analyze how much time the machine has been running under load, idling, or in downtime, ▪️monitor key parameters such as oil temperature, hydraulic pressure, and other machine data. The result – a clear overview of where energy is used effectively and where it is wasted, helping to improve both efficiency and productivity. Full story (published by ZTF Lāsma) 👉 lnkd.in/djRawMGg

Sep 20, 2025

Meisam Zamen

Senior Automation Engineer | Expert in PLC, SCADA, HMI | 10+ Years in General Electrical Engineering And Industrial Control and Automation Systems

Just wrapped up a project where the powerful trio of Siemens S7-1200 PLC, Weintek HMI, and a VEGA radar level sensor came together to create a rock-solid tank level control system. #Automation #ControlSystems #SiemensPLC #WeintekHMI #VEGA #Engineering #Manufacturing

Sep 18, 2025

Ufuk Akinci

Foreman at Panplast Irrigation

Pump control system with Fatek PLC and Weintek HMI

Aug 13, 2025

BobB

I require remote access to my projects that are away from home. I did some homework and decided that Weintek looked to have a good solution. Set up my first Weintek touch screen yesterday. I set up a domain on Weincloud - free. A secure VPN connection. I had purchased a remote access card when I purchased the screen - about $90 AUD. I set up the screen with appropriate IP addresses - modem was connected complete with an inexpensive data only SIM card - entered modem IP address as appropriate - rebooted the touch screen and clicked add screen on the cloud interface. I added the hardware number of the screen and the serial number on the access card and viola - I was connected to the screen via EasyAccess software and Weintek CMT viewer. Operating switches and the like. The hardware number and access card number are locked together. My PLC was connected to the second Ethernet port on the touch screen and my laptop was connected to the PLC as well through a switch and I was online to the PLC. I clicked on 'pass through' on the cloud connection - added the IP address of the PLC - the software noted that there already was a connection to the PLC (my laptop) - said it would be disconnected - clicked OK - my laptop Ethernet connectiion was disconnected and was then connected through the modem/cloud connection - absolutely seamless. I think back to how I used to have to connect with expensive Extranet cards - having to use a DNS server to find out the public IP address or have an expensive VPN account and program the modem mystery bag - do routing tables in the PLC software - painfull. Very impressed and the screens are not expensive - graphics pretty good as well - a heap of drivers for just about any PLC brand. I did not have to do any programming in the modem either - its default IP address was out of the way of everything so no need. In this case I used a Teleorigin modem but guess that probably any brand would do. Many have a default IP address of 192.168.1.1 which is inconvenient as that is the default address of most routers as well so the IP address would need to be changed before connecting to anything. Now on to discovering about the email feature from the screen through Weincloud using a SMTP mail server. Then on to push messages to mobiles with EasyAccess running on them. My customer will also have access to the screen from mobile phones and computers using the EasyAccess app - everyone is happy. Next one will be setup next week - will have to put together a detailed instruction sheet for my colleagues. Red Lion have a solution of course but it is so expensive and does not appear to have all the features Weintek does have.

I require remote access to my projects that are away from home. I did some homework and decided that Weintek looked to have a good solution. Set up my first Weintek touch screen yesterday. I set up a domain on Weincloud - free. A secure VPN connection. I had purchased a remote access card when I purchased the screen - about $90 AUD. I set up the screen with appropriate IP addresses - modem was connected complete with an inexpensive data only SIM card - entered modem IP address as appropriate - rebooted the touch screen and clicked add screen on the cloud interface. I added the hardware number of the screen and the serial number on the access card and viola - I was connected to the screen via EasyAccess software and Weintek CMT viewer. Operating switches and the like. The hardware number and access card number are locked together. My PLC was connected to the second Ethernet port on the touch screen and my laptop was connected to the PLC as well through a switch and I was online to the PLC. I clicked on 'pass through' on the cloud connection - added the IP address of the PLC - the software noted that there already was a connection to the PLC (my laptop) - said it would be disconnected - clicked OK - my laptop Ethernet connectiion was disconnected and was then connected through the modem/cloud connection - absolutely seamless. I think back to how I used to have to connect with expensive Extranet cards - having to use a DNS server to find out the public IP address or have an expensive VPN account and program the modem mystery bag - do routing tables in the PLC software - painfull. Very impressed and the screens are not expensive - graphics pretty good as well - a heap of drivers for just about any PLC brand. I did not have to do any programming in the modem either - its default IP address was out of the way of everything so no need. In this case I used a Teleorigin modem but guess that probably any brand would do. Many have a default IP address of 192.168.1.1 which is inconvenient as that is the default address of most routers as well so the IP address would need to be changed before connecting to anything. Now on to discovering about the email feature from the screen through Weincloud using a SMTP mail server. Then on to push messages to mobiles with EasyAccess running on them. My customer will also have access to the screen from mobile phones and computers using the EasyAccess app - everyone is happy. Next one will be setup next week - will have to put together a detailed instruction sheet for my colleagues. Red Lion have a solution of course but it is so expensive and does not appear to have all the features Weintek does have.

Apr 26, 2024

Darby Kramer, CFPS, CMRP

President and Co-Founder of Dynamic Motion Industries LLC

A little WFH for Dynamic Motion Industries LLC industries over the weekend. Project #1 is some wiring for a panel due for testing and customer delivery this week. Project #2 is the very beginning of the migration of a monitoring system from an android tablet to a Weintek USA, Inc. cMT3108 HMI and Rockwell Automation CompactLogix controller.

Feb 5, 2024

Ali Hadian

Senior Electrical Engineer - Automation - Programming PLC and HMI

In Pegah dairy industries, we made improvements to the Tetra Pak filling machine (TBA19-020v) HMI (Human Machine Interface) using Weintek design and programming tools. The new HMI boasts a more user-friendly design, making operation and troubleshooting significantly easier for our operators.

Jun 3, 2024

Umar Farooq

BS Electrical Engineering | GIKI 24'

Excited to share the details of a recent project I worked on! Designed and implemented a complete monitoring and control system. Here’s what we accomplished: - Used sensors for temperature, humidity, and differential pressure in each tank. - Two valves for each tank —one for gas purging and the other for exhaust. - Designed a pressure-controlled system where the upper and lower pressure limits (set via a Weintek HMI) controlled the system operations. - Added user-defined upper and lower limits for temperature, pressure, and humidity, with alarms for all these parameters. - Configured digital feedback for valve statuses (open, closed, or intermediate), displayed on the HMI system monitor for real-time tracking. - Implemented datalogging to record valve operations (open/close) and high/low alarms for pressure, temperature, and humidity. -Developed real-time graphs for pressure, temperature, and humidity on the HMI to monitor trends and system behavior visually. - Also added feature for remote monitoring and control using Easy access 2.0. This project was an incredible experience, combining automation, real-time monitoring, and data management into a robust and user-friendly system!

Jan 25, 2025

Vahid Heydari

Senior PLC programmer & Automation Engineer

Commissioning of the Crystallizer Unit in a Granule Production Plant - Troubleshooting and wiring of equipment - Calibration and adjustment of sensors - Modifications to the PLC and HMI programs PLC: S7 1214 | HMI: WEINTEK | VFD: Panasonic

Mar 3, 2025

Richard Arancibia

Ingeniero civil mecatrónico - Técnico Eléctrico - Automatización

🚀 HMI Weintek USA, Inc. + PLC Siemens Automation is not an expense, it is a strategic investment: it optimizes costs, minimizes risks and accelerates your industrial competitiveness. In this video I remotely programmed and commissioned an industrial system Alutipo Group Material Movement 🚀 Experts

Jul 15, 2025

base32_25

Honestly they are all pretty good, under 10inch and standalone machine i go with the IE/iP series, simply because of the price, nothing comes close. Anything bigger or part of the PLC network I go with CMT X series, you can set them up to access all the CMT HMIs from any other CMT HMI, obviously all password protected but I have a headless CMT HMI in my office connected to a big monitor showing me every HMI on the plant, it's no replacement for a good scada system but it still allows me to make adjustments and monitor data at a glance without loading up or running extra applications on my laptop. But any of them will work, and that's the biggest benefit to me, 1 version of 1 application will do them all

Jan 11, 2024

LibrarySpecialist396

I actually like them. I have used their HMIs in the past and liked them for most "simple" applications. They have a ton of very useful options, and their driver support is excellent. Yes, I have done a few from scratch. For instance, the program for the scenario I listed in this post has about 19 screens with anything from trends to recipe management. Took me a couple weeks (I am the only controls engineer at my plant, so I couldn't work on it all day every day lol)

May 23, 2025

James Dean

Owner at Appalachian Automation, LLC.

Update on the animation projects for the machine system we are fabbing now. this project is about a month out from finished. we are building the pusher in the bottom shop now and and I an working on the HMI and code. this should be clean and as always, Weintek and Keith Moyer has knocked it out of the park with this product!

Aug 2, 2023

Javier Navarro Jr

PLC Programmer and Controls Technician at Schrader Mechanical

Made this bad boy from scratch for PLC trouble shooting,sorry my phone kinda sucks. #EasyBuilderPro #Weintek

Aug 9, 2023

James Dean

Owner at Appalachian Automation, LLC.

why every company doesn't offer black as a color is beyond me....

Aug 31, 2023

James Dean

Owner at Appalachian Automation, LLC.

couldn't be more happy with how this is turning out. The guys outdid themselves on this one. FAT next week.

Oct 2, 2023

Ehst Systems and Controls

Happy Monday! Check out our newest panel featuring a Weintek HMI

Dec 11, 2023

Wilfredo Molina

Electronics Engineer. HSEF Specialist.

We're almost ready to commission our new calibration fuel additive injector test loop. #additive #injection #biobor #yaskawa #weintek #fuel #automation #integration #TCS3000

Jan 22, 2024

Umair Sohail

Communication between Weintek HMI and INVT VFD through RS485. The HMI displays the Basic parameter of the motor, which is used for an Amusement Ride. -Weintek MT8072iP -INVT CHF-100A-011G #Engineering #Design #Automation #Technology #Automation

May 24, 2024

Darby Kramer, CFPS, CMRP

President and Co-Founder of Dynamic Motion Industries LLC

Some action shots from a 3 panel build for a customer in Iowa. These three control panels will control the temperature in soup kettles. The customer is currently running an open loop system with manual temperature recording. Dynamic Motion Industries LLC is providing them a closed loop solution with real time monitoring and emailed reports to their quality team. These panels are slotted for install and commissioning the end of this week. This system uses a Rockwell Automation Micro 850 with a Real Time Clock module and an RTD expansion module. We are using ifm PT100 Stainless Steel 24” sensors and displaying it all on a Weintek USA, Inc. HMI.

Jun 3, 2024

Jared Ehst

Owner/Partner, Technical Engineer at Ehst Systems and Controls

Technical breakdown of the Ideal Manufacturing LLC Cope Machine: This two station cope machine is demonstrated here being fed by a UR 20. This robot is a bit overkill for the application but accomplishes the job with its impressive 68in reach. The control system for this machine is based on a Beckhoff Automation CX series processor which enabled easy to implement multi-axis motion control and logic control. We also rely on the TwinSAFE platform to seamlessly manage the safety logic for this machine. Phoenix Contact supplies safe zero speed monitoring for the 2 high speed 9kw spindles powered by Lenze i500 series VFDs over EtherCAT. These spindles have quick change HSK tool holders and are capable of 12000 RPM in this configuration. Compact motion control keeps the cabinet size low with the EL72xx series drives which drive the Beckhoff AM8000 servo motors to provide reliable, precise motion for cutting and positioning of the spindles in 3 dimensional space in combination with Apex gearboxes and Metal Work's linear actuators. The spindle gantry is built of 3/4in steel to reduce vibration and improve cut quality. This results in a gantry with estimated weight of 300lbs. Pneumatics are controlled using Metal Works EB80 IO-Link valve bank with an interrupted power section for safe state operation. Weintek offers this clean, quality HMI from the CMTX series and easy communication to the PLC over ADS. For more information on the woodworking features and specs of operation on this machine go to idealmanufacturingllc.com

Aug 8, 2024

Jordan Ehst

Owner, Designer, Programmer at Ehst Systems and Controls

Stopped by to add a feature to a small project you did several years ago. It isn't the prettiest machine ever but it's a fun little piece. Beckhoff Automation USA Weintek

Jun 10, 2024

Adam Thraves MIET

Controls Engineer at Self Employed

#Throwback to a recent project – a precision loss in weight system designed for a packing line. The system accurately measured batched weights of roasted beans for seamless production at every step. Programmed using Siemens TIA portal, the system tracked and logged precise coffee amounts for optimal efficiency. ✅

Jul 9, 2024

Bitmasked Automation

Agricultural Automation: Providing systems integration through practical, flexible, automated solutions.

Existing customer called with a problem, their project was being delayed by control panel lead times. A basic lead/lag pump panel based on level. The spec called for relay logic, indicator lights and mercury switches. With customer approval we updated this to modern times with a VEGA Americas, Inc. radar level sensor, PLC control and Weintek USA, Inc. HMI for easy user adjustments and remote operation. Designed, assembled and programmed in 10% of the originally quoted timeframe. Can't always knock them out this quick, but when the timing allows and the programs are straightforward, things move quick. #plcprogramming #automation #freshproduce #systemsintegrator

Aug 21, 2024

Bitmasked Automation

Great things come in small packages. These compact panels are headed out to various sites for monitoring grain bin levels with VEGA Americas, Inc. radar levels sensors and Weintek USA, Inc. HMIs. A few have some simple extra logic that was requested such as stacklight operation, auto swap between bins based on level and auto shutdown based on amperage. Custom routed enclosures from Polycase, Inc. keeps things neat and professional.

Aug 28, 2024

Bitmasked Automation

Agricultural Automation: Providing systems integration through practical, flexible, automated solutions.

Ease of use is a key feature in #agautomation. Coupling a VEGA Americas, Inc. radar with a Weintek USA, Inc. HMI and WERMA stacklights provides simple, reliable and easy to use level monitoring for any grain system. VEGA's intuitive VEGA Tools app allows customers to configure radars on their own with ease over bluetooth. Weintek's flexibility in design makes it easy to hide away rarely used settings in pop-ups, making field configuration easy on a less cluttered HMI with hierarchical design. WERMA's new RST56 provides a sharp contrast vs traditional stacklights with colored lenses, making it easier to distinguish which light segments are illuminated.

Sep 4, 2024

Wilfredo Molina

Electronics Engineer. HSEF Specialist.

What would you do if you needed to measure high frequency inputs in a PLC-based application? In my experience, I always prefer to relieve the PLC of this burden and utilize a separate module for high-frequency measurements. For example, I recently investigated the capabilities of the new Weintek iR-PU01-P module, which can receive pulse input at up to 2MHz, and the findings were extremely positive. Despite the fact that the PU01-P is a 1-axis module designed for motion control, it has proven to be an extremely useful solution for measuring simple high frequency pulses from our TCS product flow meters in our fuel additive injection calibration loop, improving performance, reducing PLC load, and increasing accuracy and scalability.

Oct 3, 2024

Bitmasked Automation

There's several alternatives to radar for bin level sensing. 🪨 Throw stones at the side of the bin. 🪜 Climb the ladder constantly. 🪟 Mechanical indicators that fill w/water. 🎡 Rotary switches combined with a stopwatch for how long to fill after the light turns on and a notepad to remember to tell grandpa there's already 2 loads past the switch. 📷 Cameras... That magically see through dust and debris. ➕ Math, grain in - grain out. EzPz. Or just add radar and remove the guesswork.

Sep 18, 2024

Dave Thompson

Northland Controls & Automation

My latest creation. Remote water pumping station controls. 5 pumps, Tank levels, pressures all controlled and logged via a Weintek cmtx 10" HMI with Codesys. with Odot Ethernet/IP remote io and Eaton control gear. Using Easyaccess2.0 from Weintek and a cellular 4g router to give remote access, control and alarm monitoring. #Weintek #Codesys #Eaton #Odot

Oct 14, 2024

CME ENGINEERING

🚀 Proud to share our latest achievement at Sona Hospital, Fauji Fertilizer Company Limited! We provided automation services and installed an electrical panel for their 2000 LPH plant. The panel was built using Delta PLC ES2 series and Weintek MT8071IE, seamlessly integrated with an INVT VFD for optimal control and performance. 🌟 💡 Delivering automation solutions that make a difference!

Oct 17, 2024

Saqib Ali

Student @ IIPD Global Lahore | Associate Electrical Engineer

"Revolutionizing Denim Pants Production with Automation: A Success Story" HSA (Pvt.) Ltd. (Leather Division) Introduction As an automation expert, I'm thrilled to share a recent success story where I designed and implemented a comprehensive automation solution for a spray booth machine used in denim pants production. This project showcases the power of automation in transforming manufacturing processes. The Challenge: The client's existing spray booth machine was manually operated, resulting in inconsistent product quality, reduced efficiency, and increased labor costs. The goal was to automate the process to improve product quality, reduce production time, and minimize waste. The Solution: To address the challenge, I designed and built a custom control panel, developed a Fatek PLC program, and created a user-friendly HMI (Human-Machine Interface) for the spray booth machine. The automation solution featured: - Automated Pressure control - Spray nozzle control - Alarm and notification system - Real-time monitoring and data analysis through the HMI Results: The implementation of the automation solution resulted in significant improvements in production efficiency, product quality, and reduced labor costs. The client reported: - 30% increase in production efficiency - 20% reduction in labor costs - Improved product quality and consistency Conclusion: This project demonstrates the transformative power of automation in manufacturing. By designing and implementing a comprehensive automation solution, we were able to streamline the denim pants production process, resulting in significant cost savings and improved product quality.

Jan 9, 2025

Total Automation Systems

In this stage, we commissioned the functionality of four Centronik valves equipped with electronic positioners, utilizing Profibus DP as the communication protocol between our Siemens CPU 1200 series and the associated equipment. The project also involved integrating temperature and pressure sensors and developing a user-friendly HMI interface for the end user. Our team was actively involved in every stage of the project, starting from electrical work, cable pulling and marking, and lighting system setup, to PLC software development. Additionally, we provided comprehensive training to the beneficiary's personnel to ensure the proper operation and efficient utilization of the installation. For the HMI development, we leveraged Weintek technology, a versatile solution offering advanced features, including the ability to import user-defined symbols to enhance the interface's functionality and customization.

Jan 12, 2025

Engr Muhammad Abdullah

PLC | HMI | SCADA | DCS | SIEMENS Tia Portal & Simatic Manager

Communication of Siemens S7-1200 with WEINTEK HMI via Ethernet port module/switch

Jan 29, 2025

Jeremy Pollard

Automation veteran with Allen Bradley / Rockwell expertise (Legacy included)

Just implemented on for Canbus on a 95 ft yacht!!!! for battery monitoring.. the EBPro Sware is pretty slick.. there tech support is good too:) hardware=solid!

Feb 4, 2025

Weintek Love in the Wild
